DETECTION TECHNOLOGY
At Neutron Insights, we design and develop custom radiation detection and scientific instrumentation systems, combining detector physics, sensor materials, photodetectors, electronics, signal processing and experimental validation.
We don’t sell standard detectors. We develop custom detection solutions tailored to your experiment, materials and measurement requirements.
- Detector design
- Scintillator and radiation-sensitive material integration
- SiPM / photodetector integration
- Detector arrays
- Analog electronics
- Multichannel acquisition
- Signal processing
- Mechanical integration
- Characterization
- Prototype development
Our products:
Directional cosmic detector
Model NI-CRPD-A26
A directional cosmic radiation detector designed for research applications, scientific instrumentation, and monitoring purposes. The detector consists of two parallel planes, each composed of a 2×2 matrix of scintillating plastic modules covered with reflective foil. This dual-plane configuration allows for the detection of particle passage and the acquisition of directional information from cosmic radiation.
Gamma Radiation and Charged Particle Detector
Model NI-GCPD-A26
It is a modular system. The main detector head has a 25 × 25 channel matrix. Each channel consists of: an inorganic scintillation crystal of thallium-doped cesium iodide (CsI(Tl)) measuring 30×30×40 mm with a reflective coating, a solid-state photodetector bonded with optical cement, and a connector for signal output with a coaxial cable. The 25 detection units are housed within a frame that closes at the front with a removable cover that must be dismounted to measure charged particles, and another cover at the rear that has 5 rectangular holes through which the signal output connectors exit. All of this is assembled on top of a base to provide greater stability.
Ultraviolet (UV) Radiation Detector with Integrated Computer Vision for Safety Applications
Our “NI-DUVIA3D” system combines cutting-edge UV sensor technology, advanced electronics, data analysis, and IoT for early detection of ignition sources, providing an effective tool to mitigate risks and protect both people and the environment.
Specialized Electronics for Instrumentation,
Sensing, and Detection Systems
Custom design and development of electronics for detection systems, sensors, and scientific and industrial instrumentation. Development of analog and digital circuits, multichannel data acquisition systems, signal processing, and hardware-software integration.
Applications:
- Scientific instrumentation
- Industrial sensing
- Data acquisition
- Multichannel systems
- NDT and industrial inspection
- IoT.
Need a detector for your experiment?
We develop custom radiation detection systems for research and industrial applications, from detector design and scintillator/photodetector integration to electronics, data acquisition and complete instrumentation.
